Specifications

• Dimensions

  add remove
  • Length:
    2325 mm
  • Seat height, unladen:
    680 mm
  • Ground clearance:
    120 mm
  • Rake:
    30
  • Trail:
    150 mm
  • Wheelbase:
    1625 mm
  • Tyres, front specifications:
    130/70B18 63H BW
  • Tyres, rear specifications:
    180/70B16 77H BW
  • Fuel capacity:
    18.9 l
  • Oil capacity:
    4.4 l
  • Weight, as shipped:
    304 kg
  • Weight, in running order:
    317.06 kg
  • Luggage capacity – volume:
    1.9 cu ft (0.05 m³)
  • Tyre, type:
    Michelin™ Scorcher™ "31" front and rear
• Engine

  add remove
  • Engine:
    Milwaukee-Eight® 107
  • Bore:
    100 mm
  • Stroke:
    111 mm
  • Displacement:
    1746 cm³
  • Compression ratio:
    10.0:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    2-into-1; catalyst in muffler
• Performance

  add remove
  • Engine torque testing method:
    EC 134/2014
  • Engine torque:
    139 Nm
  • Engine torque (RPM):
    3500
  • Horsepower:
    82 HP / 61 kW @ 5020 rpm
  • Lean angle, right (deg.):
    28
  • Lean angle, left (deg.):
    29
  • Fuel economy testing method:
    EU 134/2014
  • Fuel economy:
    5.5 l/100 km
  • CO₂ emissions testing method:
    EU 134/2014
  • CO₂ emissions:
    128 g/km CO₂
• Drivetrain

  add remove
  • Primary drive:
    Chain, 34/46 ratio
  • Gear ratios (overall) 1st:
    9.311
  • Gear ratios (overall) 2nd:
    6.454
  • Gear ratios (overall) 3rd:
    4.793
  • Gear ratios (overall) 4th:
    3.882
  • Gear ratios (overall) 5th:
    3.307
  • Gear Ratios (overall) 6th:
    2.79
• Chassis

  add remove
  • Front fork:
    Single cartridge 43 mm inverted with aluminum fork triple clamps; triple rate spring
  • Rear shocks:
    Hidden, free piston, coil-over monoshock; 43mm stroke; toolless hydraulic pre-load adjustment
  • Wheels, front type:
    Black, machine highlighted, Mantis cast aluminum
  • Wheels, rear type:
    Black, machine highlighted, Mantis cast aluminum
  • Brakes, type:
    Front black, split 7-spoke floating rotor, rear solid, uniform expansion rotor
  • Brakes, caliper type:
    4-piston fixed front and 2-piston floating rear
• Electric

  add remove
  • Lights (as per country regulation), indicator:
    High beam, turn signals, neutral, low oil pressure, engine diagnostics, cruise, ABS, security, low battery voltage, low fuel
  • Gauges:
    5-inch analog speedometer with digital gear, odometer, fuel level, clock, trip, range and tachometer indication
